6257

Side 2 Polarity :
Side 2 Body Style :
Impedance :
Adapter Style :
Frequency Range :
Contact Plating :
Shell Plating :
Body Material :
Side 1 Polarity :
Side 1 Body Style :
Side 1 Gender : Plug (Male)
Side 2 Gender : Plug (Male)
Side 1 RF Series : N
Side 2 RF Series : 7/16


Features:

- Wide supply voltage range                        5.0Vdc to 36Vdc
                                                                +2.5Vdc to +18Vdc
- Very low supply current drain (0.4mA Typ)
  independent of supply voltage
- Low input biasing current                                     25nA Typ
- Low input offset current                                       +3nA Typ
  and maximum offset voltage                     +5mV Max (25 C)
- Input common-mode voltage range includes ground
- Differential input voltage range
  equal to the power supply voltage
- Low output saturation voltage               250mV at 4mA Typ
- Output voltage compatible with TTL,
  DTL, ECL, MOS and CMOS logic systems


Specifications

Supply Voltage, V+
                                                          36Vdc or +18Vdc
Differential Input Voltage
(Note 3)
                                                          36V
Output Voltage
                                                          36V
Input Voltage
                                                          -0.3V to +36V
Input Current (Vin < -0.3Vdc)
(Note 2)
                                                          50mA
Power Dissipation
  METAL CAN                                       330mW at TA = 125 C
  CERDIP                                             400mW at TA = 125 C
Maximum Junction Temperature
                                                           175 C
Output Short-Circuit to GND
(Note 1)
                                                           Continuous
Operating Temperature Range
                                                           -55 C to +125 C
Thermal Resistance
ThetaJA
 CERDIP
  (Still Air)                                             146 C/W
   (500 LF/Min Air Flow)                        85 C/W
 METAL CAN
  (Still Air)                                             174 C/W
  (500 LF/Min Air Flow)                         99 C/W
ThetaJC
   CERDIP                                              33 C/W
   METAL CAN                                        44 C/W
Storage Temperature Range
                                                             -65 C to +150 C
Soldering Information
  Soldering, (10 seconds)                      260 C
ESD Tolerance
(Note 4)
                                                              500V
Note 1: Short circuits from the output to V+ can cause excessive heating and eventual destruction. When considering short circuits to ground, the maximum output current is approximately 20mA independent of the magnitude of V+.

Note 2: This input current will only exist when the voltage at any of the input leads is driven negative. It is due to the collector-base junction of the input PNP transistors becoming forward biased and thereby acting as input diode clamps. In addition to this diode action, there is also lateral NPN parasitic transistor action on the IC chip. This transistor action can cause the output voltages of the comparators to go to the V+ voltage level (or to ground for a large overdrive) for the time duration that an input is driven negative. This is not destructive and normal output states will re-establish when the input voltage, which was negative,again returns to a value greater than -0.3Vdc.

Note 3: Positive excursions of input voltage may exceed the power supply level. As long as the other voltage remains within the common-mode range, the comparator will provide a proper output state. The low input voltage state must not be less than -0.3Vdc (or 0.3Vdc below the magnitude of the negative power supply, if used).

Note 4: Human body model, 1.5K Ohms in series with 100pF.

Description

The LM193 consists of two independent precision voltage comparators which were designed specifically to operate from a single power supply over a wide range of voltages.Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. These comparators LM193 also have a unique characteristic in that the input common-mode voltage range includes ground,even though operated from a single power supply voltage.

Application areas of LM193 include limit comparators, simple analog to digital converters; pulse,squarewave and time delay generators; wide range VCO; MOS clock timers; multivibrators and high voltage digital logic gates. The LM193 was designed to directly interface with TTL and CMOS. When operated from both plus and minus power supplies, the LM193 will directly interface with MOS logic where their low power drain is a distinct advantage over standard comparators.

Parameters:

Technical/Catalog Information	6257
Vendor	Pomona Electronics
Category	Connectors
Convert From (Adapter End)	N Jack, Female Socket
Convert To (Adapter End)	7/16 Plug, Male Pin
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	6257 6257
