Circuit Board Hardware - PCB 200u SN/PB OVER NI 15 CON
6002-0-19-01-15-01-10-0: Circuit Board Hardware - PCB 200u SN/PB OVER NI 15 CON
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
US $.14 - .19 / Piece
Circuit Board Hardware - PCB SOLDER MNT PIN RECPT
US $.4 - .4 / Piece
Circuit Board Hardware - PCB 200u SN/PB OVER NI 15 CON
US $.45 - .45 / Piece
Circuit Board Hardware - PCB 10u AU OVER NI 15 CON
Technical/Catalog Information | 6002-0-19-01-15-01-10-0 |
Vendor | Mill Max |
Category | Connectors |
Type | Socket, Tail |
Mounting Type | Solder Mount |
Flange Diameter | 1.626 mm [Typ] |
Flange Thickness | 1.270 mm [Nom] |
Outside Diameter | 1.448 mm [Typ] |
Inner Diameter | 0.813 mm [Typ] |
Length Above Board | 1.270 mm [Typ] |
Length Below Board | 6.604 mm [Typ] |
Socket Depth | 3.175 mm [Typ] |
Through Hole Size | 1.499 mm [Min] |
Feature(s) | Closed Bottom |
Packaging | Bulk |
Contact Material | Beryllium Copper |
Contact Finish | Tin-Lead |
Operating Temperature | -55 °C [Min] |
Operating Temperature | 125 °C [Max] |
Other Names | 6002 0 19 01 15 01 10 0 6002019011501100 6002 019011501100 ND 6002019011501100ND 6002-019011501100 |
