552ARI-01LF

Specifications

Temperature I Voltage 3.3 V Package QSOP 20 Speed NA Core Supply Voltage (VDD) 3.3V - 5V No. of Outputs 8 Min. Output Frequency 10MHz Min. Input Frequency 10MHz Output Supply Voltage (VDDO) 3.3V - 5V No. of Inputs 1 Input Style Single Ended,Crystal Max. Output Frequency 200MHz Max. Input Frequency 200MHz Output Style Single Ended Temp. Grade C Supply Voltage


Description

OSCILLATOR, MULTIPL
The ICS552A-01 produces 8 low-skew copies of the multiple input clock or fundamental, parallel-mode crystal. Unlike other clock drivers, these parts do not require a separate oscillator for the input. Using IDT's patented Phase-Locked Loop (PLL) to multiply the input frequency, ICS552A-01 is ideal for generating and distributing multiple high-frequency clocks. This is a single chip used for 3 different applications:
1) ICS552A-01 (A mode) - an Oscillator mutiplier
2) ICS552A-01 (B mode) - a Dual 1:4 buffer
3) ICS552A-01 (C mode) - a 1:8 Oscillator buffer

ICS552A-01 features:

Packaged as 20-pin SSOP (QSOP)

Pb-free packaging available

Operating voltages of 3.0 V to 5.5 V

Industrial temperature available
