54AC125SMQB_1354743

If Military/Aerospace specified devices are required, please contact the National Semiconductor Sales Office/Distributors for availability and specifications.
Supply Voltage (V_CC)                                             -0.5V to a7.0V
DC Input Diode Current (I_K)
V_I= -0.5V                                                                 -20 mA
V_I = V_CC a 0.5V                                                       +20 mA
DC Input Voltage (_VI)                                            -0.5V to V_CC a 0.5V
DC Output Diode Current (IOK)
V_O= -0.5V                                                             -20 mA
V_O= V_CC a 0.5V                                                    +20 mA
DC Output Voltage (V_O)                                       -0.5V to V_CC a 0.5V
DC Output Source
or Sink Current (I_O)                                              ±50 mA
DC VCC or Ground Current
per Output Pin (I_CC or I_GND)                                ±50 mA
Storage Temperature (T_STG)                               -65 to +150
Junction Temperature (T_J)
CDIP                                                                    175
PDIP                                                                     140
Note 1: Absolute maximum ratings are those values beyond which damage to the device may occur. The databook specifications should be met, without exception, to ensure that the system design is reliable over its power supply, temperature, and output/input loading variables. National does not recommend operation of FACTTM circuits outside databook specifications.
