54ABT374

Storage Temperature ...........................................................................−65 to +150
Ambient Temperature under Bias .........................................................−55 to +125
Junction Temperature under Bias
  Ceramic ..............................................................................................−55 to +175
V_CC Pin Potential to
   Ground Pin ..........................................................................................−0.5V to +7.0V
Input Voltage (Note 2) ...........................................................................−0.5V to +7.0V
Input Current (Note 2) ....................................................................−30 mA to +5.0 mA
Voltage Applied to Any Output
   in the Disabled or
   Power-Off State ....................................................................................−0.5V to 5.5V
   in the HIGH State ..................................................................................−0.5V to V_CC
Current Applied to Output
   in LOW State (Max) .............................................................twice the rated I_OL (mA)
DC Latchup Source Current:
   OE Pin ..........................................................................................................−150 mA
   (Across Comm Operating Range)
   Other Pins ....................................................................................................−500 mA
Over Voltage Latchup (I/O) .....................................................................................10V

The 54ABT374 is an octal D-type flip-flop featuring separate D-type inputs for each flip-flop and TRI-STATE outputs for bus-oriented applications. A buffered Clock (CP) and Output Enable (OE) are common to all flip-flops.
