5306H3-5V

LED Circuit Board Indicators AMBER DIFFUSED

product image

5306H3-5V Picture
See larger image
SeekIC No. : 0029642 Detail

5306H3-5V: LED Circuit Board Indicators AMBER DIFFUSED

5306H3-5V Data Sheet

floor Price/Ceiling Price

US $ .38~.54 / Piece | Get Latest Price
Part Number:
5306H3-5V
Mfg:
Chicago Miniature
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~500
  • Unit Price
  • $.54
  • $.49
  • $.43
  • $.38
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Packaging : Bulk

Description

LED Size :
Illumination Color :
Lens Color/Style :
Wavelength :
Luminous Intensity :
Mounting Type :
Viewing Angle :
Packaging : Bulk


Pinout




Specifications

Part Number: 5306H3-5V
Serial Number: 5306H
Emitted color: Amber
Lens color: Amber
Lum in min (mcd): 2
Lum in typ (mcd): 8.0
Rated current (mA): 10
Cont forward current max: 15.0
Fwd volts type: 5.0
Forward volt max.: 7.5
Reverse breakdown V: 5
Viewing angle (°): 60
Peak wave length (mA): 583
Housing type: UL94V-0
RoHS Status: Yes


Description

CML LED assemblies 5306H3-5V are available in both right angle and vertical package and utilize the CML IT line of high quality LEDs. Parts range in voltage from 2V to 12V and in current from 2mA to 20mA. The UL94V0 housings ensure proper LED alignment.
