50A-E

Features: ` ADJUSTABLE SWITCHING FREQUENCY UP TO 200 kHz` CURRENT MODE CONTROL` SOFT START AND SHUTDOWN CONTROL` AUTOMATIC BURST MODE OPERATION IN STAND-BY CONDITION ABLE TO MEET BLUE ANGEL NORM (<1w TOTAL POWER CONSUMPTION)` INTERNALLY TRIMMED ZENER REFERENCE` UNDERVOLTAGE LOCK-OUT WITH HYST...

product image

50A-E Picture
See larger image
SeekIC No. : 004232174 Detail

50A-E: Features: ` ADJUSTABLE SWITCHING FREQUENCY UP TO 200 kHz` CURRENT MODE CONTROL` SOFT START AND SHUTDOWN CONTROL` AUTOMATIC BURST MODE OPERATION IN STAND-BY CONDITION ABLE TO MEET BLUE ANGEL NORM (&...

50A-E Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
50A-E
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` ADJUSTABLE SWITCHING FREQUENCY UP TO 200 kHz
` CURRENT MODE CONTROL
` SOFT START AND SHUTDOWN CONTROL
` AUTOMATIC BURST MODE OPERATION IN STAND-BY CONDITION ABLE TO MEET"BLUE ANGEL" NORM (<1w
   TOTAL POWER CONSUMPTION)
` INTERNALLY TRIMMED ZENER REFERENCE
` UNDERVOLTAGE LOCK-OUT WITH HYSTERESIS
` INTEGRATED START-UP SUPPLY
` OVER-TEMPERATURE PROTECTION
` LOW STAND-BY CURRENT
` ADJUSTABLE CURRENT LIMITATION



Specifications

Symbol
Parameter
Value
Unit
VDS
 Continuous Drain-Source Voltage (TJ = 25 to 125)
-0.3 to 700
V
ID
 Maximum Current
Internally limited
A
VDD
 Supply Voltage
0 to 15
V
VOSC
 Voltage Range Input
0 to VDD
V
VCOMP
 Voltage Range Input
0 to 5
V
ICOMP
 Maximum Continuous Current
±2
mA
VESD
 Electrostatic Discharge (R =1.5kΩ; C=100pF)
4000
V
ID(AR)
 Avalanche Drain-Source Current, Repetitive or Not Repetitive
(Tc=100; Pulse width limited by TJ max; < 1%)
1
A
Ptot
 Power Dissipation at Tc = 25
60
W
Tj
 Junction Operating Temperature
Internally limited
Tstg
 Storage Temperature
-65 to 150



Description

VIPer50A-E/ASP-E, made using VIPower M0 Technology, combines on the same silicon chip a state-of-the-art PWM circuit together with an optimized, high voltage, Vertical Power MOSFET (700V/ 1.5A).

Typical applications of VIPer50A-E/ASP-E cover offline power supplies with a secondary power capability of 25W in wide range condition and 50W in single range or with doubler configuration. VIPer50A-E/ASP-E is compatible from both primary or secondary regulation loop despite using around 50% less components when compared with a discrete solution. Burst mode operation is an additional feature of this device, offering the ability to operate in stand-by mode without extra components.
