4363D1/5

Illumination Color :
Luminous Intensity :
Wavelength/Color Temperature :
Viewing Angle :
Lens Color/Style :
Forward Current :
Forward Voltage :
LED Size :
Packaging : Bulk


Specifications

Part Number: 4363D1/5
Serial Number: 4363D
LED Type: THRU HOLE
Industry Size: Rectangular
Metric Size: 2 x 5 mm
Output Color: RED/GREEN
Epoxy: WHITE DIFFUSED
Peak Wave length (mA): 635/565
Minimum MCD: 2.1/2.6
Typical MCD: 3.5/4.0
Forward Volt (Typical): 1.9/2.1
Forward Volt (Max): 2.4/2.7
Rate Current (mA): 20
Viewing Angle (°): 100
Operating Temperature: -20 C to +85 C
Storage Temperature: -55 C to +100 C
Power Dissipation: 135
Cont Forward Current Max: 25
RoHS Status: Yes




Description

4363D1/5 Series Solid State LED Lamps-Tri-Color 2mm x 5mm 4 description and features.The first one is 3 lead design provides 3 color output.The second one is two chips matched for brightness..The third one of the 4363D1/5 is Rectangular shape.The fourth one is Diffused on surface, even light distribution,wide viewing angle.

The 4363D1/5 Series Solid State LED Lamps-Rectangular 1.8 x 5.3mm Tri-Color has some datas about electro-optical characteristics and ratings.Red:Diffus ion is diffused.P ackage Color is C lear.R ated Current (mA) is 20.Forward Voltage Typ. (V) is 1.9 .Forward Voltage Max. (V) is 2.4 .Luminous Intensity Min. (mcd) of the 4363D1/5 is 2.1 .Luminous Intensity Typ. (mcd) is 3.5 .Capacitance @ V=0 (pF) is 11.Peak Wavelength (nm) is 635.Viewing Angle 20 1/2 (degrees ) is 100.Power Dissipation (mW) is 135.Continuous Forward Current Max. (mA) is 25.R everse Breakdown Voltage Min. (V) of the 4363D1/5 is 5.Peak Forward Current Max. (1ms-300pps) (mA) is 90.Green:Diffus ion is diffused.P ackage Color is C lear.R ated Current (mA) is 20.Forward Voltage Typ. (V) is 2.1 .Forward Voltage Max. (V) is 2.7 .Luminous Intensity Min. (mcd) is 2.1 .Luminous Intensity Typ. (mcd) is 4.0 .Capacitance @ V=0 (pF) is 18.Peak Wavelength (nm) of the 4363D1/5 is 565.Viewing Angle 20 1/2 (degrees ) is 100.Power Dissipation (mW) is 135.Continuous Forward Current Max. (mA) is 25.R everse Breakdown Voltage Min. (V) is 5.Peak Forward Current of the 4363D1/5 Max. (1ms-300pps) (mA) is 90.
