4362D1/5

Illumination Color :
Luminous Intensity :
Wavelength/Color Temperature :
Viewing Angle :
Lens Color/Style :
Forward Current :
Forward Voltage :
LED Size :
Packaging : Bulk


Pinout






Specifications

Part Number: 4362D1/5
Serial Number: 4362D
LED Type: THRU HOLE
Industry Size: Rectangular
Metric Size: 1.8 x 5.3 mm
Output Color: RED/GREEN
Epoxy: WHITE DIFFUSED
Peak Wave length (mA): 700/565
Minimum MCD: .25/1.70
Typical MCD: 0.6/4.5
Forward Volt (Typical): 2.2
Forward Volt (Max): 2.8
Rate Current (mA): 15.0/20.0
Viewing Angle (°): 130
Operating Temperature: -0.294117647
Storage Temperature: -0.3
Power Dissipation: 70/90
Cont Forward Current Max: 30
RoHS Status: Yes




Description

The 4362D1/5 Series Solid State LED Lamps-Rectangular 1.8 x 5.3mm Tri-Color has 4 description and features.The first one is tri-color LED - red, green and amber LED chip in same lamp.The second one of the 4362D1/5 is rectangular shape - diffused lens.The third one is red and green light output is uniform.The fourth one is 3 leaded design with common cathode.

The 4362D1/5 Series Solid State LED Lamps-Rectangular 1.8 x 5.3mm Tri-Color has some datas about electro-optical characteristics and ratings.Output Color is R ed/Green.Diffus ion is Diffused.Package Color of the 4362D1/5 is C lear.R ated Current (mA) is 15.0 .Forward Voltage Typ. (V) is 2.2 .Forward Voltage Max. (V) is 2.8 .Luminous Intensity Min. (mcd) is .25/1.5 .Luminous Intensity Typ. (mcd) is .6/4.5 .Peak Wavelength (nm) of the 4362D1/5 is 700/565.Viewing Angle 20 1/2 (degrees) is 60.Power Dissipation (mW) is 115.Continuous Forward Current Max. (mA) is 20.

At present there is not too much information about this model.If you are willing to find more about the 4362D1/5 Series Solid State LED Lamps-Rectangular 1.8 x 5.3mm Tri-Color, please pay attention to our web! We will promptly update the relevant information.
