Features: SpecificationsDescription The 4304H is Series Solid State LED Lamps-Super Brite 30 mcd T-1 3/4 (5mm).The 4304H has 2 description and features.The first one is High-intensity light output.The second one is Wide viewing angle.
The 4304H has some information about electro - optical characteristics and ratings.The 4304H1:Output Color is red,diffus ion is Diffused,package color is red,test current (mA) is 10,forward Voltage Typ. (V) is 2.0,forward Voltage Max. (V) is 3.0,luminous Intens ity Min. (mcd) is 3.0,luminous Intens ity T yp. (mcd) is 6.3,capacitance @ V=0 (pF) is 45,peak Wavelength (nm) is 650,viewing Angle 20 1/2 (degrees) is 65,power Dissipation (mW) is 60,R everse Breakdown Voltage Min. (V) is 5.The 4304H3:Output Color is amber,diffus ion is Diffused,package color is ember,test current (mA) is 10,forward Voltage Typ. (V) is 2.2,forward Voltage Max. (V) is 3.0,luminous Intens ity Min. (mcd) is 4.0,luminous Intens ity T yp. (mcd) is 20,capacitance @ V=0 (pF) is 4,peak Wavelength (nm) is 608,viewing Angle 20 1/2 (degrees) is 60,power Dissipation (mW) is 135,R everse Breakdown Voltage Min. (V) is 5.The 4304H5:Output Color is green,diffus ion is Diffused,package color is green,test current (mA) is 10,forward Voltage Typ. (V) is 2.1,forward Voltage Max. (V) is 3.0,luminous Intens ity Min. (mcd) is 3.0,luminous Intens ity T yp. (mcd) is 10,capacitance @ V=0 (pF) is 20,peak Wavelength (nm) is 563,viewing Angle 20 1/2 (degrees) is 75,power Dissipation (mW) is 75,R everse Breakdown Voltage Min. (V) is 5.The 4304H7:Output Color is yellow,diffus ion is Diffused,package color is yellow,test current (mA) is 10,forward Voltage Typ. (V) is 2.1,forward Voltage Max. (V) is 3.0,luminous Intens ity Min. (mcd) is 2.5,luminous Intens ity T yp. (mcd) is 6.3,capacitance @ V=0 (pF) is 45,peak Wavelength (nm) is 585,viewing Angle 20 1/2 (degrees) is 65,power Dissipation (mW) is 60,R everse Breakdown Voltage Min. (V) is 5.
Chicago Miniature Lamp reserves the right to make specification revisions that enhance the design and/or performance of the 4304H.
