42115

Features:

* Wide Supply Voltage Range (±10 to ±50 Volts)
* High Output Current (5A Peak)
* Small Size (TO-3, 8 Pins)
* Low Cost




Application

* Programmable Power Supplies
* Motor, Valve & Actuator Controls
* Audio Amplifiers
* Magnetic Deflection Circuits




Specifications

Power Supply Voltage (V_CC).......................................................±50VDC
Differential Input Voltage .........................................................±V_CC -3V
Common Mode Input Voltage ..........................................................±V_CC
Operating Temperature Range (case) ........................-55°C to +125°C
Storage Temperature Range........................................-65°C to +150°C
Output Current .............................................................................5A Peak
Power Dissipation at TC = 25°C ........................................................67W
Lead Temperature (Soldering < 10 sec)........................................+300°C




Description

The 42115 ( DSCC Drawing #5962-9082801) is a high power, high voltage, high current, power operational amplifier which also is an alternate to the popular OPA511 and PA10. The high current output stage delivers 5A and has externally adjustable current limiting capability. This 42115 Hybrid IC is housed in an 8 pin, hermetic TO-3 and is designed for driving inductive, capacitive and resistive loads.
