390LP4E

Features: Pout: +4.7 dBmPhase Noise: -112 dBc/Hz @100 KHzNo External Resonator NeededSingle Supply: 3V @ 42 mAQFN Leadless SMT Package, 16 mm2ApplicationLow noise MMIC VCO w/Buffer Amplifi er for:• Wireless Local Loop (WLL)• VSAT & Microwave Radio• Test Equipment & Indust...

product image

390LP4E Picture
See larger image
SeekIC No. : 004229474 Detail

390LP4E: Features: Pout: +4.7 dBmPhase Noise: -112 dBc/Hz @100 KHzNo External Resonator NeededSingle Supply: 3V @ 42 mAQFN Leadless SMT Package, 16 mm2ApplicationLow noise MMIC VCO w/Buffer Amplifi er for:&#...

390LP4E Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
390LP4E
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

Pout: +4.7 dBm
Phase Noise: -112 dBc/Hz @100 KHz
No External Resonator Needed
Single Supply: 3V @ 42 mA
QFN Leadless SMT Package, 16 mm2


Application

Low noise MMIC VCO w/Buffer Amplifi er for:
• Wireless Local Loop (WLL)
• VSAT & Microwave Radio
• Test Equipment & Industrial Controls
• Military


Pinout

Connection Diagram


Specifications

Vcc +3.5 Vdc
Vtune 0 to +11V
Channel Temperature 135
Continuous Pdiss (T = 85)
(derate 6.28 mW/ above 85)		 565W
Storage Temperature -65 to -150
Operating Temperature -40 to +85



Description

The HMC390LP4 & HMC390LP4E are GaAs InGaP Heterojunction Bipolar Transistor (HBT) MMIC VCOs with integrated resonators, negative resistance devices, varactor diodes, and buffer amplifi ers.

Covering 3.55 to 3.9 GHz, the VCO's phase noise performance is excellent over temperature, shock, vibration and process due to the oscillator's monolithic structure. Power output is 4.7 dBm typical from a single supply of 3V @ 42 mA. The voltage controlled oscillator is packaged in a low cost leadless QFN 4 x 4 mm surface mount package.
