Features: ·DUAL CHANNEL PROCESSOR FOR PLAY- BACK APPLICATIONS.·STEREO DOLBY B NR SYSTEM·LOW NOISE HEAD PREAMPLIFIER·MUTE, AMS (AUDIO MUSIC SENSOR)FUNCTIONS·INTERNAL SWITCHES FOR EQUALIZATION·DOLBY REFERENCE LEVEL -6dBm (388.2mVRMS)·MINIMUM NUMBER OF EXTERNAL COMPO-NENTS·LOW SUPPLY CURRENT (18mA)·M...
38035: Features: ·DUAL CHANNEL PROCESSOR FOR PLAY- BACK APPLICATIONS.·STEREO DOLBY B NR SYSTEM·LOW NOISE HEAD PREAMPLIFIER·MUTE, AMS (AUDIO MUSIC SENSOR)FUNCTIONS·INTERNAL SWITCHES FOR EQUALIZATION·DOLBY R...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Features: `Basic machine-language instructions ...................................... 71`Minimum i...
Symbol | Parameter | Value | Unit |
Vs | Supply Voltage | 12 | V |
Ptot | Total Power Dissipation | 1 | W |
Top | Operating Temperature Range | -40 to 85 | |
Tstg | Storage Temperature Range | -40 to 150 |
The 38035 is a monolithic BICmos IC de- signed for use in stereo cassette player systems. The device includes two separate audio channels composed by low noise preamplifier, Dolby B noise reduction system and Audio Music Sensor. The dual preamplifier contains mute, metal/nor- mal facilities for amplification of low level signal in applications requiring very low noise perform- ances.
Each channel consists of two cascaded opera-tional amplifiers.
The first one, AMP1, has a fixed gain of 36dB, and allows magnetic heads connection directly to ground. The second one, AMP2, is a standard op- erational amplifier whose equalizing external components fix the frequency response.
The Audio Music Sensor circuit detects the inter- program space and then the starting point of mu- sical programs (the interprogram time and pro- gram detection time are externally selectable). The device contains Dolby B decoder NR chains requiring very few external components and do not require coils.
