37845

Operation Temperature Commercial ...........................................................................................................0to 70
Storage Temperature............................................................................................................................-65 to 125
Applied V_CC Voltage with Respect to VSS............................................................................................... -0.6V to 7.0V
Applied Voltage on Input Pin with Respect to VSS...................................................................................-0.6V to 7.0V
Applied Voltage on Output Pin with Respect to VSS ...................................................................... -0.6V to V_CC+0.5V
Applied Voltage on A9 Pin with Respect to VSS .................................................................................... -0.6V to 13.5V
Applied V_PP Voltage with Respect to VSS...............................................................................................-0.6V to 13.5V
Applied READ Voltage (Functionality is guaranteed between these limits) ............................................+3.0V to 3.6V
Note: These are stress ratings only. Stresses exceeding the range specified under "Absolute Maximum Rating" may cause substantial damage to the device. Functional operation of this device at other conditions beyond those listed in the specification is not implied and prolonged exposure to extreme conditions may affect device reliability.

The 37845 chip family is a low-power, 4096K (4,194,304) bits, +3.3V electrically one-time programmable (OTP) read-only memories (EPROM). Organized into 256K words with 16 bits per word, 37845 features a fast single address location programming, typically at 75s per word. Any word can be accessed in less than 90ns with respect to spec. This eliminates the need for WAIT states in high-performance microprocessor systems. The 37845 has separate Output Enable (OE) and Chip Enable (CE) controls which eliminate bus contention issues.
