3631

      Bourns 3631 VDSL POTS Splitter is designed to simplify the deployment of VDSL service at the customer premises. ANSI T1E1.4 compliant, the 3631 accepts the incoming VDSL service and filters off the voice (POTS) and ISDN channels and provides a connection for DSL data services (VDSL modem). In the event of power loss, the passive filter design allows for lifeline POTS service.The 3631 occupies only a single space in 7600 style Network Interface Devices (NIDs) or the Bourns 7043 enclosures. Fitted with screw terminals and flying leads, the 3631 can be installed in minutes.
      It has five unique features.The first one is fast and easy DSL installation. The second is optimal data rates.The third one is service interoperability and compatibility . The forth one is multiple "Home Run" connections. And the last one is UL Listed per 1863.
      Next , there are some characteristics about it . DC Loop Current is 0 ma to 100 ma. DC Loop Voltage is 0 V to -60 V. DC Resistance is equal to and less than 25ohms.Insertion Loss is less than 1.0 dB (25 kHz -1.104 MHz). Attenuation Distortion (Voice Band)  is less than +0.5 dB or -0.5dB. Delay Distortion (Voice and ISDN Band) is less than 200 s. Return Loss (Voice Band) is as follows : 6 dB ERL,5 dB SRL-Low and 3.0 dB SRL-High.Tip to Ring Capacitance (POTS Port) is less than 90 nf.
