Features:

900 mA/12 V or 400 mA/24 V Operation

Speed-Control (PWM) Capability

Locked-Rotor Indication

 Minimum External Components

Over-Current Protected

Thermal Protection

Enhanced Reliability

Reduced Cost




Application

Care should be taken in evaluating the package power dissipation of these devices.  Total power dissipated by the device will consist of power due to the internal regulator, logic and drive circuitry (ICC x VCC), power due to the output drivers (IO x VO(SAT)), and power due to the clamp circuitry (ICL x VCL x duty cycle).




Specifications

Characteristic

Symbol

Test Conditions

Limits

Min. Typ. Max.

Units

Operate Point§

BOP



- ±100 ±150

G

Hysteresis

BH



- 200 -

G

Output Current Limit Ratio

lO/lO MAX

RADJ = 39 k

- 0.75 -

-

RADJ = 17 k

- 0.50 -

-

RADJ = 10 k

- 0.25 -

-

PWM Control Current

IADJ

VADJ = 0

- -350 -500

A

Tach Output Leak. Curren

IT

V = 14 V

- - 10

A

Tach Output Sat. Voltage

VT(SAT)

IT = 750 A

- 0.2 0.4

V

Thermal Shutdown

TJ



165 -

°C

Thermal Hysteresis

TJ



10 -

°C
