Specifications | Input Frequency | 5 MHz to 50 MHz |
| No. of Inputs | 1 |
| Temperature | I |
| Output Frequency | 250 kHz to 200 MHz |
| Input Type | Clock,Crystal |
| No. of Outputs | 3 |
| Output Type | LVCMOS |
| Voltage | 5.0 V |
| Package | SOIC 8 |
| Speed | NA |
| Spread Type | Down,Center |
| Core Supply Voltage (VDD) | 3.3 V |
| Output Supply Voltage (VDDO) | 3.3 V |
| Peak-to-Peak Period Jitter | ± 200 ps Pk-to-Pk |
| Spread Spectrum | Yes |
| VCXO | No |
| Output Style | SE |
| Input Style | Crystal |
| Max. Output Frequency | 200 MHz |
| Min. Output Frequency | 0.25 MHz |
| Max. Input Frequency | 50 MHz |
| Min. Input Frequency | 2 MHz |
| Temp. Grade | C |
DescriptionFIELD PROGRAMMABLE TRIPLE
The 343MIP is a low-cost, triple-output, field programmable clock synthesizer. The 343MIP can generate an output frequency from 250 kHz to 200 MHz, using up to three independently configurable PLLs. The outputs may employ Spread Spectrum techniques to reduce system electromagnetic interference (EMI).
Using IDT VersaClock software to configure the PLL and output, the 343MIP contains a One-Time Programmable (OTP) ROM to allow field programmability. Using Phase-Locked Loop (PLL) techniques, the device runs from a standard fundamental mode, inexpensive crystal, or clock. It can replace multiple crystals and oscillators, saving board space and cost.
The 343MIP also has a power-down feature that tri-states the clock outputs and turns off the PLLs when the PDTS pin is taken low.
The 343MIP is also available in factory programmed custom versions for high-volume applications.
8-pin SOIC package
Highly accurate frequency generation
M/N Multiplier PLL: M = 1...2048, N = 1...1024
Output clock frequencies up to 200 MHz
Spread spectrum capability for lower system EMI
Center or Down spread up to 4% total
Selectable 32 kHz or 120 kHz modulation
Input crystal frequency of 5 to 27 MHz
Input clock frequencies from 2 to 50 MHz
Operating voltage of 3.3 V
Advanced, low-power CMOS process
For one output clock, use the ICS341. For two output clocks, see the ICS342. For more than three outputs, see the ICS345 or ICS348
Available in Pb (lead) free package
