3269X-1-504LF, US $ 1.66-2.66 , Bourns, 3269X-1-504LF DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 001262339 Detail

3269X-1-504LF: Trimmer Resistors - SMD 1/4" 500Kohms 10% Horizontal Adjust

3269X-1-504LF Data Sheet

US $ 1.66~2.66 / Piece | Get Latest Price

Part Number:: 3269X-1-504LF
Mfg:: Bourns
Supply Ability:: 5000

Price Break

Qty
0~1
1~10
10~50
50~100

Unit Price
$2.66
$2.41
$2.08
$1.66

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/10/30

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

3269 evaluate
US $7.4 - 8.55 / Piece

Test Plugs & Test Jacks BNC TO BANANNA
32690 evaluate
US $15.13 - 15.13 / Piece

PLIER EXTER RETAIN RING 3/8-1"
32691 evaluate
US $15.72 - 15.72 / Piece

PLIER EXTER RETAIN RING 19-60MM

Product Details

Quick Details

Product :	Trimmers	Product Type :	Multiturn
Number of Turns :	12	Element Type :	Cermet
Taper :	Linear	Resistance :	500 KOhms
Voltage Rating :	300 Volts	Termination Style :	SMD/SMT
Power Rating :	250 mWatts (1/4 Watt)	Tolerance :	10 %
Temperature Coefficient :	100 PPM / C

Description

Element Type : Cermet
Termination Style : SMD/SMT
Tolerance : 10 %
Temperature Coefficient : 100 PPM / C
Product Type : Multiturn
Power Rating : 250 mWatts (1/4 Watt)
Taper : Linear
Product : Trimmers
Voltage Rating : 300 Volts
Resistance : 500 KOhms
Number of Turns : 12

Parameters:

Technical/Catalog Information	3269X-1-504LF
Vendor	Bourns Inc.
Category	Potentiometers, Variable Resistors
Resistance In Ohms	500K
Power (Watts)	0.25W, 1/4W
Number of Turns	12
Package / Case	Square - 0.250" L x 0.170" W x 0.293" H (6.35mm x 4.32mm x 7.44mm)
Packaging	Tube
Adjustment Type	Side Adjustment
Tolerance	±10%
Mounting Type	Surface Mount
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	3269X 1 504LF 3269X1504LF
