301CNQ...PbF SERIES

      The 301CNQ...PbF SERIES center tap schottky rectifier module series has been designed to optimize for low reverse leakage at high temperature.The user could has a reliable operation up to 175 °C junction temperature with the help of the proprietary barrier technology.Its typical applications are in plating power supplies,high current switching power supplies,UPS systems, converters, free-wheeling diodes,welding, and reverse battery protection.
      301CNQ...PbF SERIES have seven features.The first one is that it would have a 175 °C Tj operation.The second one is that it has the center tap module.The third one is that it would have low forward voltage drop.The fourth one is that it would have a high frequency operation.The fifth one is that it would have guard ring for enhanced ruggedness and long term.The sixth one is that it would have a strong reliability.The last one is that it would be lead-free.
      Some major ratings and characteristics of 301CNQ...PbF SERIES have been concluded into several points.The first one is about its I F(AV) rectangular waveform would be 300 A.The second one is about its V(RRM) range which would be from 40 to 45 V.The third one is about its I(FSM) @ tp = 5 s sine which would be 16,000 A.The fourth one is about its VF @ 150Apk at TJ=125°C(per leg) which would be 0.59 V.The last one is about its VJ range which would be from - 55 to 175 °C.
      And also the absolute maximum ratings of 301CNQ...PbF SERIES have been conclude into four points.The first one is IF(AV) which would be 300A of max. average forward per device and 150A of current per leg.The second one is about its I(FSM) which would be 16000A of max. peak one cycle non-repetitive and 3200A of surge current (Per Leg).The third one is about its E(AS) Nnn-repetitive avalanche energy (Per Leg) which would be 202 mJ at the condition of TJ = 25 °C, IAS = 21 Amps, L = 1 mH.
