2SD2195

      The 2SD2195 is a power transistor(100V,2A),and it has 4 features including Darlington connection for high DC current gain;Built-in resistor between base and emitter;Built-in damper diode;Complements the 2SB1580 / 2SB1316 / 2SB1567.
      The absolute maximun ratings of the 2SD2195 at Ta=25°C unless otherwise noted having Collector-base Voltage VCBO is 100V;Collector-emitter Voltage VCEO is 100 V;Emitter-base Voltage VEBO is 6 V;Collector Current (DC)IC is 2A;Junction temperature is +150°C ;Storage temperature is -55 to +150°C ;collector power Dissipation Pc is 2 W etc.
