2SB1706TL: Transistors Bipolar (BJT) PNP 30V 2A

2SB1706TL Data Sheet

US $ .09~.09 / Piece | Get Latest Price

Part Number:: 2SB1706TL
Mfg:: ROHM Semiconductor
Supply Ability:: 5000

Price Break

Qty
0~3000
3000~6000

Unit Price
$.09
$.09

Processing time
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

2SB1000 evaluate
Application Low FREQUENCY POWER AMPLIFIER Complementary pair with 2SD1366 Specifications It...
2SB1000A evaluate
Application Low FREQUENCY POWER AMPLIFIER Complementary pair with 2SD1366A Specifications I...
2SB1001 evaluate
Application· Low frequency power amplifier· Complementary pair with 2SD1367Specifications P...

Product Details

Quick Details

Transistor Polarity :	PNP	Collector- Emitter Voltage VCEO Max :	30 V
Emitter- Base Voltage VEBO :	6 V	Maximum DC Collector Current :	2 A
DC Collector/Base Gain hfe Min :	270 at 200 mA at 2 V	Configuration :	Single
Maximum Operating Frequency :	280 MHz	Maximum Operating Temperature :	+ 150 C
Mounting Style :	SMD/SMT	Package / Case :	TSMT-3
Packaging :	Reel

Description

Configuration : Single
Maximum Operating Temperature : + 150 C
Mounting Style : SMD/SMT
Packaging : Reel
Transistor Polarity : PNP
Emitter- Base Voltage VEBO : 6 V
Collector- Emitter Voltage VCEO Max : 30 V
Maximum DC Collector Current : 2 A
Maximum Operating Frequency : 280 MHz
Package / Case : TSMT-3
DC Collector/Base Gain hfe Min : 270 at 200 mA at 2 V

Parameters:

Technical/Catalog Information	2SB1706TL
Vendor	Rohm Semiconductor
Category	Discrete Semiconductor Products
Transistor Type	PNP
Voltage - Collector Emitter Breakdown (Max)	30V
Current - Collector (Ic) (Max)	2A
Power - Max	500mW
DC Current Gain (hFE) (Min) @ Ic, Vce	270 @ 200mA, 2V
Vce Saturation (Max) @ Ib, Ic	370mV @ 75mA, 1.5A
Frequency - Transition	280MHz
Current - Collector Cutoff (Max)	-
Mounting Type	Surface Mount
Package / Case	TSMT3
Packaging	Tape & Reel (TR)
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	2SB1706TL 2SB1706TL
