2DE19P

Features: • Contact rating: 5 amps max, except BR Series (2 amps max.)• Minimum contact centers: 0.075 (1.91).• Wire sizes: #22 thru #26 AWG, stranded or solid.• Contact termination: Multiple indent crimp.• Contact retention: Crimp snap-in/removable.• Contact ma...

product image

2DE19P Picture
See larger image
SeekIC No. : 004218481 Detail

2DE19P: Features: • Contact rating: 5 amps max, except BR Series (2 amps max.)• Minimum contact centers: 0.075 (1.91).• Wire sizes: #22 thru #26 AWG, stranded or solid.• Contact term...

2DE19P Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
2DE19P
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/20

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Contact rating: 5 amps max, except BR Series (2 amps max.)
• Minimum contact centers: 0.075 (1.91).
• Wire sizes: #22 thru #26 AWG, stranded or solid.
• Contact termination: Multiple indent crimp.
• Contact retention: Crimp snap-in/removable.
• Contact materials and finish: Copper alloy, gold- plated per ASTM B488, Type II, Code C, Class 1.25.
• Mating/unmating force: 12 oz. per contact, max.


Description

2DE19P are especially suitable for commercial applications such as computers, instrumentation, communications and audio equipment. They are available in D subminiature size metal shell rectangular, plastic shell rectangular and strip configurations.

All 2DE19P use the reliable twist pin contact design in a 5 amp version terminated on .075 (1.91) and .100 (2.54) centers. The Centi contact is crimp removable, connectors are available for customer assembly. Standard crimp and assembly tools are available. The twist pin contact is recessed within the insulator housing while the rugged cylindrical socket is exposed.

When the 2DE19P halves are mated, the chamfered sockets guide the pins into positive alignment. The CentipinTM contact, now under compression, forms a multi-point contact with the CentisocketTM to provide a high degree of reliability.
