2609C

Features:

  1 GHz flat response, ±0.5 dB
   High responsivity:
     - >0.85 A/W at 1310 nm
     - 0.95 A/W at 1550 nm
  Internal current gain, 6 dB (typ.)
 75 W impedance-matched


Application

 Extended bandwidth, broadband CATV receivers


Specifications



Parameter	Symbol	Min	Max	Unit
Operating Case Temperature Range	TC	40	85
Storage Temperature Range	Tstg	40	85
Optical Input Power	PIN	-	2	mW
dc Bias Voltage	VPD	-	25	V
Forward Current	IF	-	10	mA

Description

The 2609C is a packaged impedance-matched photodiode module with internal gain designed for use in optical broadband receivers in fiber-optic networks.The patented impedance-match technology results in improved gain-bandwidth product compared to external circuits due to control of parasitics between 2609C and the impedance-matching circuit.
