Product Details

Description

Specifications

Maximum Power Dissipation @ 25        22 Watts
Maximum Voltage and Current
BV_ces   Collector to Emitter Voltage      40 Volts
BV_ebo      Emitter to Base Voltage           3.5 Volts
I_c             Collector Current                   1.25 Amps
Maximum Temperatures
Storage Temperature                   - 40 to + 200
Operating Junction Temperature              + 200

Description

The 2224-6L is a COMMON BASE transistor capable of providing 6 Watts, Class C output power over the band 2200-2400 MHz. The transistor includes input prematching for full Broadband capability. Gold metalization and diffused ballasting are used to provide high reliability and supreme ruggedness. The 2224-6L transistor uses a fully hermetic High Temperature Solder Sealed package.
