1EGG8-2

Contact Plating :
Housing Material :
Operating Temperature Range :
Connector Type :
Filtered : Yes
Product : Inlets
Mounting Style : Flange
Current Rating : 1 A
Filter Type : EMI/RFI Filter
Voltage Rating : 250 VoltsAC
Termination Style : IEC 320 C14


Description

The 1EGG8-2 power entry modules combine the functions of a general purpose RFI filter with an IEC power cord connector and single or dual metric fusing, in the smallest possible panel space. A choice of .250" terminals or wire leads is available for the load-side terminations.

For maximum cost effectiveness, 6 amp models should be used for all applications rated 6 amps or less, unless the higher performance of the 3 amp models, or the much higher performance of the 1 amp models, is needed. Models with C-suffix additionally incorporate a ground choke1 to isolate the equipment chassis from external ground at RF frequencies.

Parameters:

Technical/Catalog Information	1EGG8-2
Vendor	Tyco Electronics
Category	Filters
Type	IEC 320-C14 (Male Pins)
Mounting Type	Panel Mount, Screw Hole
Termination Style	Wire Leads
Current	1A
Voltage	250V
Features	Fuse Holder
Filter Type	RFI
Fuse Drawer	Included
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	1EGG8 2 1EGG82
