1604941-1: Pin & Socket Connectors 12P BULKHEAD CONN SEALED

1604941-1 Data Sheet

US $ 2.74~3.28 / Piece | Get Latest Price

Part Number:: 1604941-1
Mfg:: TE Connectivity
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~50
50~100

Unit Price
$3.28
$3.01
$2.87
$2.74

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/5/31

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

1604 evaluate
US $.25 - .38 / Piece

Cable Mounting & Accessories SR 6P3-7S
1604 SL021 evaluate
US $96.29 - 111.68 / Piece

Flat Cable 26AWG 4C UNSHLD 1000ft SPOOL SLATE
1604 SL030 evaluate
US $47.78 - 56.34 / Piece

Multi-Conductor Cable 26AWG 4C UNSHLD 328ft SPOOL SLATE

Product Details

Quick Details

Product Type :	Receptacle Housings	Contact Gender :	Pin (Male), Socket (Female)
Pitch :	6.35 mm	Number of Positions / Contacts :	12
Number of Rows :	4	Mounting Style :	Through Hole
Termination Style :	Quick Connect	Housing Material :	Nylon
Voltage Rating :	600 V	Current Rating :	19 A

Description

Series :
Contact Material :
Contact Plating :
Product Type : Receptacle Housings
Number of Positions / Contacts : 12
Termination Style : Quick Connect
Voltage Rating : 600 V
Mounting Style : Through Hole
Housing Material : Nylon
Current Rating : 19 A
Pitch : 6.35 mm
Contact Gender : Pin (Male), Socket (Female)
Number of Rows : 4

Parameters:

Technical/Catalog Information	1604941-1
Vendor	Tyco Electronics
Category	Connectors
Color	Natural
Contact Termination	Crimp
Contact Type	Male or Female
Mounting Type	Panel Mount, Bulkhead
Number of Rows	3
Pitch	0.250" (6.35mm)
Packaging	Bulk
Connector Type	Receptacle
Fastening Type	Ramp
Features	-
Number of Positions	12
Row Spacing	0.250" (6.35mm)
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	1604941 1 16049411 A32538 ND A32538ND A32538
