1517

The 1517-series device is a fixed, single-input, five-output, passive delay line. The signal input (IN) is reproduced at the outputs (T1-T5) in equal increments. The delay from IN to T5 (T_D) is given by the device dash number. The characteristic impedance of the 1517-series is given by the letter code that follows the dash number (See Table). The rise time (T_R) of the 1517-series is 33% of T_D, and the 3dB bandwidth is given by 1.05 / T_D.
