1516

Terminal Block Type: Barrier Block
Pitch: 0.375" (9.53mm)
Current: 20A
Barrier Type: 2 Wall (Dual)
Packaging: Bulk
Number of Rows: 2
Top Termination: Screws
Bottom Termination: Closed
Features: Flange
Number of Circuits: 16
Number of Wire Entries: 32
Manufacturer: Curtis Industries
Voltage: -
Color: -
Wire Gauge: 12 AWG
Series: 1500


Features:

· 5 taps of equal delay increment
· Delays to 200ns
· Low profile
· Epoxy encapsulated
· Meets or exceeds MIL-D-23859C


Pinout




Description

The 1516-series device is a fixed, single-input, fiveoutput, passive delay line. The signal input (IN) is reproduced at the outputs (T1-T5) in equal increments. The delay from IN to T5 (TD) and the characteristic impedance of the 1516-series (Z) are determined by the dash number. The rise time (TR) of the 1516-series is 30% of TD, and the 3dB bandwidth is given by 1.05 / TD.

The 1516-series is available in a 8-pin DIP (1516) or a 8-pin SMD (1516S), and a wide range of pinouts may be specified. Part numbers of the 1516-series are constructed according to the scheme shown at right. For example, 1516C-101-500B is a 290 mil DIP, 100ns, 50W delay line with pinout code B. Similarly, 1516SB-151-501 is a 240 mil SMD, 150ns, 500W delay line with standard pinout.
