Product Details

Description

Features:

Package in 8mm tape on 7diameter reel.
Compatible with automatic placement equipment.
Compatible with infrared and vapor phase reflow solder process.
Mono-color type.
Pb-free.
The product itself will remain within RoHS complaint version.

Application

Automotive: backlighting in dashboard and switch.
Telecommunication: indicator and backlighting in telephone and fax.
Flat backlight for LCD, switch and symbol.
General use.

Specifications

Parameter	Symbol	Rating	Unit
Reverse Voltage	V_R	5	V
Forward Current	I_F	30	mA
Operating Temperature	T_opr	-40 ~ +85
Storage Temperature	T_stg	-40~ +90
Electrostatic Discharge(HBM)	ESD	1000	V
Power Dissipation	P_d	130	mW
Peak Forward Current (Duty 1/10 @1KHz)	I_F	70	mA
Soldering Temperature	T_sol	Reflow Soldering : 260 for 10 sec. Hand Soldering : 350 for 3 sec.

Description

The 15-21C430 SMD Taping is much smaller than lead frame type components, thus enable smaller board size, higher packingdensity, reduced storage space and finally smaller equipment to be obtained.
Besides, lightweight of the 15-21C430 makes them ideal for miniature applications. etc.
