1417K5A

Small form factor, RJ-45 size, 20-pin package
LC duplex receptacle
Uncooled 1300 nm laser transmitter with automatic output power control
Transmitter disable input
Wide dynamic range receiver with InGaAs PIN photodetector
Recovered clock outputs
TTL signal-detect output
Low power dissipation
Single 3.3 V power supply
LVPECL/CML compatible data inputs and CML compatible data outputs
Operating temperature range: 0to70
Agere Systems Inc. Reliability and Qualification Program for built-in quality and reliability

The 1417K5A transceiver is a high-speed, cost-effec-tive optical transceiver intended for 2.488 Gbits/s shelf-to-shelf optical interconnect applications as well
as SONET SR OC-48 and SDH I-16. The 1417K5A features proven Agere Systems optics and is packaged in a narrow-width plastic housing with an LC duplex receptacle. The receptacle fits into an RJ-45 form factor outline. The 1417K5A 20-pin package pinout con-forms to a multisource transceiver agreement.

The 1417K5A features the ability to interface to both LVPECL and CML differential logic level data inputs. The 1417K5A also features a TTL logic level disable input and laser bias and back-facet monitor outputs. The receiver features differential CML logic level data and clock outputs, a TTL logic level signal-detect output and direct access to the PIN photodetector bias input for photocurrent monitoring purposes.
