139RPFX

Features:

• Rad-Pak® technology-hardened against natural space radiation
• Total dose hardness: - >100 krad (Si), depending upon orbit and space mission
• Single Event Effects: - SEL > 59.8 MeV/mg/cm2
• Package:
• - 14 pin Rad-Pak® flat package
• Wide supply voltage range- 2 VDC to 36 VDC or ±1 VDC to ±18 VDC
• Very low supply current drain: - (0.8 mA) - independent of supply voltage
• Low input biasing current: 25 nA
• Differential input voltage range equal to the power supply voltage
• Low output saturation voltage: 250 mV at 4 mA
• Power drain suitable for battery operation
• Allows sensing near GND
• Eliminates need for dual supplies
• Output voltage compatible with TTL, DTL, ECL, MOS and CMOS logic systems
• Low input offset current and offset voltage:-+5 nA, +3 mV


Pinout




Specifications

PARAMETER	SYMBOL	MIN	MAX	Unit
Supply Voltage (V+ - V-)	V+ - V-	36 VDC or ±18 VDC		V
Differential Input Voltage1		-	36	V
Input Voltage		-0.3	+36	V
Open Short-Circuit to Ground2		Continuous
Input Current (VIN < -0.3VDC)		--	50	mA
Power Dissipation	PD	--	1	W
Storage Temperature Range	TS	-65	1	°C
Operating Temperature Range	TA	-55	125	°C
ESD Tolerance		--	600	V

Description

Maxwell Technologies 139RPFX consisting of four independent precision voltage comparators, features a greater than 100 krad (Si) total dose tolerance, depending upon space mission. Using Maxwell Technologies radiation- hardened Rad-Pak® packaging technology, the 139 has an offset voltage specification as low as 2 mV max for all four comparators. The 139RPFX was also designed specifically to operate from a single power supply over a wide range of voltages. Operation from split power supplies is possible and the low power supply current drain is independent of the magnitude of the power supply voltage. These comparators also have a unique characteristic in that the input common-mode voltage range includes ground, even though operated from a single power supply voltage.
