1337GCSRI

Specifications

Package SOIC 16 Speed NA Temperature I Voltage 1.8 V Core Supply Voltage (VDD) 1.8V to 5.5V Integrated 32 kHz crystal Yes Interface I2C Memory Type N/A Time of Day Alarms 2 Time-Keeping Current (nA) 425 Trickle-Charge Capability


Description

RTC BASE
The 1337GCSRI device is a low power serial real-time clock (RTC) device with two programmable time-of-day alarms and a programmable square-wave output. Address and data are transferred serially through an I2C bus. The device provides seconds, minutes, hours, day, date, month, and year information. The date at the end of the month is automatically adjusted for months with fewer than 31 days, including corrections for leap year. The clock operates in either the 24-hour or 12-hour format with AM/PM indicator.

Applications

Telecommunication (Routers, Switches, Servers)

Handhelds (GPS, POS terminals, MP3 players)

Set-Top Box, Digital Recording

Office (Fax/Printers, Copiers)

Medical (Glucometer, Medicine Dispensers)

Other (Thermostats, Vending Machines, Modems, Utility Meters, Digital Photo Frame devices)

Features:

Real-Time Clock (RTC) counts seconds, minutes, hours, day, date, month, and year with leap-year compensation valid up to 2100

Packaged in 8-pin MSOP, 8-pin SOIC, 16-pin QFN (without integrated crystal), or 16-pin SOIC (surface-mount package with an integrated crystal)

I2C Serial interface (Normal and Fast modes)

Two time-of-day alarms

Oscillator Stop Flag

Programmable square-wave output defaults to 32 kHz on power-up

Operating voltage of 1.8 to 5.5 V

Industrial temperature range (-40 to +85°C)
