124 SERIES

      124 SERIES has many types of products. PACK QUANTITY = 20 PIECES. their features are:1.Extra firm fixed lead frame allowing easy population of circuit board; 2. Material conforms to UL94 V-O flammability ratings; 3. Reverse polarity options available; 4. Custom built multi-colour permutations; 5. Product illustrated 122-000-04-52; 6. Typically available ex stock.
      when Ta = 25°C, Ordering Information & Typical Technical Characteristics: NO.1. 124-305-04 is red, leds is Colour Diffused, VOLTAGE DC Vopr is 2.0, CURRENT DC lopr is 20, LUMINOUS INTENSITY lv@20mA is 40, WAVE LENGTH lp is 627, OPERATING TEMP Topr is -40 ~ +85^, STORAGE TEMP Tstg is -40 ~ +85^. NO.2. 124-311-04 is yellow,  leds is Colour Diffused, VOLTAGE DC Vopr is 2.1, CURRENT DC lopr is 20, LUMINOUS INTENSITY lv@20mA is 30, WAVE LENGTH lp is 590, OPERATING TEMP Topr is -40 ~ +85^, STORAGE TEMP Tstg is -40 ~ +85^. NO.3: 124-314-04 is Green, leds is Colour Diffused, VOLTAGE DC Vopr is 2.2, CURRENT DC lopr is 20, LUMINOUS INTENSITY lv@20mA is 40, WAVE LENGTH lp is 565, OPERATING TEMP Topr is -40 ~ +85^, STORAGE TEMP Tstg is -40 ~ +85^. NO.4: 124-330-04 is red/green, leds is white Diffused, VOLTAGE DC Vopr is 2.0/2.2, CURRENT DC lopr is 20, LUMINOUS INTENSITY lv@20mA is 20/16, WAVE LENGTH lp is 627/565, OPERATING TEMP Topr is -40 ~ +85^, STORAGE TEMP Tstg is -40 ~ +85^.
      Housing Material of 124 SERIES, Polycarbonate: This material offers UL94 V-0 flame retardancy and a high impact strength. This material has a melt point of 290-340°C and is suitable for use in the majority of automatic soldering processes.Material test thickness 1.6mm.
