115CNQ015ASL

Recovery Time :
Maximum Power Dissipation :
Operating Temperature Range : - 55 C to + 125 C
Product : Schottky Rectifiers
Packaging : Tube
Configuration : Dual Common Cathode
Peak Reverse Voltage : 15 V
Maximum Reverse Leakage Current : 20000 uA
Forward Continuous Current : 55 A
Mounting Style : Stud
Package / Case : D-61-8-SL
Max Surge Current : 5050 A
Forward Voltage Drop : 0.46 V at 110 A


Features:

125 T operation (V  < 5V)
 Center tap module
Optimized for OR-ing applications
Ultra low forward voltage drop
High frequency operation
ard ring for enhanced ruggedness and long term reliability
High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance
New fully transfer-mold low profile, small footprint, high current package


Specifications




Description

The 115CNQ015A center tap Schottky rectifier module has been optimized for ultra low forward voltage drop specifically for the OR-ing of parallel power supplies. The proprietary barrier technology allows for reliable operation up to 125 !a junction temperature. Typical applications of 115CNQ015A are in parallel switching power supplies, converters, reverse battery protec- tion, and redundant power subsystems.
