1014-12

Specifications

Maximum Power Dissipation @ 2539 Watts
Maximum Voltage and Current
BVces       Collector to Emitter Voltage                                  50 Volts
BVebo      Emitter to Base Voltage                                        3.5 Volts
Ic              Collector Current                                                   5.0 A
Maximum Temperatures
Storage Temperature                                                  - 65 to +150
Operating Junction Temperature                                             +200


Description

The 1014-12 is a COMMON BASE  transistor capable of providing 12 Wattsof Class C, RF output power over the band 1000-1400 MHz. This transistor isdesigned for Microwave Broadband Class C amplifier applications. It includesinput prematching and utilizes gold metalization and diffused ballasting toprovide high reliability and supreme ruggedness.
