10119

The 10119 is a 4-wide 4-3-3-3-input orand gate designed for use in data control as a general purpose logic element.All unused inputs can be left open due to integrated pull-down resistors,which avoid the need for a supply voltage.

Features of the 10119 are:(1)typical propagation delay:2.3ns;(2)typical supply current(-I_EE):20mA.

The absolute maximum ratings of the 10119 can be summarized as:(1)supply voltage,V_EE:-8.0V;(2)input voltage(V_IN should never be more negative than V_EE),V_IN:0 to V_EE V;(3)output source current(continuous),I_O:-50mA;(4)storage temperature range,T_S:-55 to +150;(5)maximum junction temperature,T_J:ceramic package...+165,plastic package is +150.NOTE:operation beyond the limlits set forth in this table may impair the useful life of the device.Unless otherwise noted,these limits are specified over the operating ambient temperature range.

If you want to know more information such as the electrical characteristics about the 10119, please download the datasheet in www.seekic.com or www.chinaicmart.com .
