100390

The 100390 is a hex translator for converting F100K logic levels to TTL logic levels. Unlike other level translators, the 100390 operates using only one +5V supply. Differential inputs allow each circuit to be used as an inverting, noninverting, or differential receiver. An internal reference generator provides V_BB for single-ended operation. The standard FAST®3-STATE outputs are enabled by a common active low TTL compatible OE input. Partitioned V_CCs on chip are brought out on separate power pins, allowing the noisy TTL V_CC power plane to be isolated from the relatively quiet ECL V_CC. The 100390 is ideal for applications limited to a single +5V supply, allowing for easy ECL to TTL Interfacing.
