0922B75-37A

The 0922B75-37A is a low cost, low profile sub-miniature unbalanced to balanced transformer designed for differential inputs and output locations on wireless chipsets in an easy to use surface mount package covering dual polarized commercial Satellite bands 950 MHz 2150 MHz. The 0922B75-37A is ideal for high volume manufacturing and is higher performance than traditional wire wound baluns. The 0922B75-37A has an unbalanced port impedance of 75 and a 75 balanced port impedance*. This transformation enables single ended signals to be applied to differential ports on modern integrated chipsets. The output ports have equal amplitude (-3dB) with 180 degree phase differential. The 0922B75-37A is available on tape and reel for pick and place high volume manufacturing.
