0011-433QR1

The 0011-433QR1 is designed as one kind of radio receiver decoder device that can be configured for many different low power short range telemetry applications such as (1)general remote control systems; (2)garage door openers; (3)car, caravan, motorcycle alarms; (4)remote switching; (5)remote gates; (6)paging. And this device requires connections to the power supply 5Vdc or 12Vdc and data outputs only.

Features of the 0011-433QR1 are:(1)Miniature RF Receiver /Decoder; (2)Keeloq Protocol; (3)40 Pin DIL I/C Profile; (4)Single Relay Option Available; (5)Supplied As AM or FM; (6)LED Indication Of Data Reception; (7)Easy Learn Transmitter Feature; (8)CMOS/TTL Outputs, Momentary or Latching; (9)Single Supply Either 5V or 12V; (10)Contacts 2A @ 12V; (11)Available 433Mhz @ 10mW; (12)Requires No Radio Licence.

The absolute maximum ratings of the 0011-433QR1 can be summarized as:(1)Supply Voltage (+12Vcc to GND): -0.3 to +17 Volts;(2)Supply Voltage (+5Vcc to GND): -0.3 to +6 Volts;(3)Storage Temperature: -30 to +85o Celsius;(4)Operating Temperature: 0 to +55o Celsius.

The electrical characteristics of the 0011-433QR1 can be summarized as:(1)Supply Voltage for +12 V: 9 to 16.0 V;(2)Supply Voltage for +5 V: 4.5 to 5.5 V;(3)Operating Temperature Range: 0 to 70;(4)Supply Current (quiescent): 9 mA;(5)Supply Current (operating relay): 50 to 70 mA;(6)Working Frequency: 200 to 450 MHz;(7)Tuning Tolerance: +/- 0.2 to +/- 0.5 MHz;(8)-3dB Bandwidth: +/- 2 to +/- 3 MHz. If you want to know more information about the 0011-433QR1, please download the datasheet in www.seekic.com or www.chinaicmart.com .
