Remote control dimmer light circuit diagram

Published:2011/4/15 5:24:00 Author:Rebekka | Keyword: Remote control dimmer light | From:SeekIC

Infrared remote control transmitter circuit. IC1 is time base manifold 555. Parameters oscillation frequency is 1500Hz. Matched with the transmitter receiver schematic.
