Unijunction transistor circuit generates train of pulses with constant pulse width but with spacing linearly adjustable over 20.to-1 rang by voltage V, which varies trigger point of uit Q2.-A. M. Ridenour and F. Turco, Unijunction Controls Spacing Between Pulses, Electronics, 39:14, p 82-83.
