The connector circuit of Santana 2000 whole wires

Published:2011/7/12 21:40:00 Author:Borg | Keyword: connector circuit, Santana 2000 | From:SeekIC

1-igniting pulse signal input 2-shield wire ground connection; 3- normally open contactor of throttle position sensor; 4-igniting switch 50 cylinder connection; 5-ground; 6-shorts; 7-air volume meter signal voltage; 8-admission temperature sensing signal; 9-fuel pump working signal voltage input terminal; 12-Ⅰand Ⅳ cylinder injector electromagnetic coil input terminal; 13-ground; 14-shorts; 15-17-pin of the EZK electric control unit; 16,17 and 18-shorts; 19-shield wire; 20-16-pin not in connection with EZK control unit; 21- 15 cylinder wire of the igniting switch
