SAAl293 (TV) single chip microprocessor

Published:2011/7/8 9:26:00 Author:Lena | Keyword: single chip, microprocessor | From:SeekIC

SAA1293 is a single chip microprocessor applied to high/middle TV remote control system. Internal circuit consists of keyboard input and display drive circuit, remote control decoder, clock generator, A/D converter, video and system control output, picture and text driver, coordination signal generator and IM bus line and register interface circuit etc. Technology characteristicN-channel MOS technics40-pin dual-in-line plastic packageSupporting types are SAA1250 and TBA2800
