FILM_TIMING_MARK_GENERATOR

Published:2009/7/14 4:33:00 Author:May | From:SeekIC

Instrumentation recorder for plasma studies uses discharge of capacitor at beginning of each plasma pinch discharge to trigger lash tube, light from which is chopped by glass disk driven at constant speed by synchronous motor.-J. J. Pearson, Instrumentation for Plasma Propulsion, Electronics, 33:24, p 66-69.
