SLOT_ANTENNAFIER

Published:2009/7/19 23:15:00 Author:Jessie | From:SeekIC

T-bar-fed 420-Mc slot antennafier for space vehicles has gain of 10 db, 100-Mc bandwidth, and 7.8 db noise figure.-J. F. Rippin, Making the Antenna on Active Partner, Electronics, 38:16, p 93-96.
