POWER_SUPPLY_PASS_TRANSISTOR_PROTECTION_CIRCUIT

Published:2009/7/17 2:31:00 Author:Jessie | From:SeekIC

A current-limiting transistor and resistor protect the pass transistor and rectifier bridge in this linear supply.
