MODIFIED_TWIN_TRIODE_CASCODE

Published:2009/7/20 21:21:00 Author:Jessie | From:SeekIC

Plate resistor for lower-potention triode parallels top triode, which is plate load for true cascode. This increases gain of circuit by increasing average plate current and thereby transcon-ductance of bottom triode.-NBS, Handbook Preferred Circuits Navy Aeronautical Electronic Equipment, Vol. 1, Electron Tube Circuits, 1963, p N2-2.
