Published:2009/7/19 21:48:00 Author:Jessie | From:SeekIC
Fourelement cold-cathode tube operates directly from output pulse of 6292 photomultiplier receiving light output of Zns screen of alpha particle detector. Maximum counting rate is 100 counts per second.-M. H. Goosey, De-signing Cold-Cathode Tube Circuits, Electron-ics, 31:3, p 101-108.
