WARNING_LIGHT_OPERATES_FROM_BATTERY_POWER_SUPPLY

Published:2009/6/30 23:50:00 Author:May | From:SeekIC

The circuit provides illumination when darkness comes. By using the gain available in darlington transistors, this circuit is simplified to use just a photodarlington sensor, a darlington amplifier, and three resistors. The illumination level will be slightly lower than normal, and longer bulb life can be expected, since the D40K saturation voltage lowers the lamp operating voltage slightly.
