3dd15 regulator constant current source circuit

Published:2011/9/4 20:27:00 Author:TaoXi | Keyword: regulator, constant current, source circuit | From:SeekIC

This is the numerical control constant current source that can be used to charge the storage battery. The D/A converter outputs a voltage value to the in-phase port of the op amp, the two ports of the current I=Uad/sampling resistor are used to connected with the + and - poles of the storage battery. The overhead op amp is connected into the amplifier circuit with the magnification of 1/4. This device is used to measure the voltage of the storage battery. The regulator 3dd15 is as shown in the figure.
